Simulation software Quartus® Prime Design

designviewermanagement

The intuitive high-performance design environment. From design entry and synthesis to optimization, verification, and simulation, Quartus® Prime Design Software unlocks increased capabilities on devices with multi-million logic elements, providing designers with the ideal platform to meet next-generation design opportunities. Design with Agilex™ 5 FPGA E- Series with a no-cost license in Quartus Prime Pro 24.1. Preproduction Quartus Exploration Dashboard offering visual compilation results across multiple instances of Quartus Prime Software. Launch simulations directly from the Quartus Prime Graphical User Interface (GUI). Accelerate synthesis compile time with Precompiled Component (PCC) generation flow. New Synthesis Capabilities: Transition older RTL files to conform to Verilog/VHDL standards with the RTL linter tool. Improved RAM inference and the ability to suppress warnings in RTL modules. Enhanced Timing Analyzer Functionality: New scripting options and sign-off capabilities for advanced timing analysis. Visualize async CDCs and timing in Chip Planner. Advanced Link Analyzer Features and Enhancements: New Link Builder Intuitive UI for automatic channel/device import and schematic creation. Automatic link establishment with multi-lane S-parameter support for enhanced signal path management. GUI scaling with high DPI monitor support for improved user experience. Data Viewer to improve FEC code word error analysis result. Simulation Time Improvements: Faster simulation times with the new Qrun and FEC models introduced.
