Linear positioning stage L90-12+R100rotarymotorized2-axis
Add to favorites
Compare this product
Characteristics
- Orientation
- linear, rotary
- Type
- motorized
- Number of axes
- 2-axis
- Other characteristics
- compact, air bearing
- Speed
100 mm/s
Description
The RotoLinear Z(Lift) - θ (Theta) Positioning Module is a high performance dual-axis air bearing system that replaces bulkier conventional electro-mechanical actuators in pick-and-place applications. It combines the latest brushless servo motor, encoder and air bearing technologies to deliver precise, programmable position and speed control in an extremely compact package. This Z-θ stage utilizes 2-axis Planar and air bearing technologies. The drive, bearings and feedback are totally non-contact. The RotoLinear Stage has a hole-through to route auxiliary vacuum and electrical lines to the top surface of the stage. Can be installed on the Planar XY forcer to operate as robotic X-Y-Z-Theta cell.
