Shuttle storage system

A shuttle for your high rack Off we go: a storage and retrieval unit (SRU) drives into the position of the desired high-rack. The shuttle detaches itself from the SRU to drive into the storage channel. The warehouse goods or the storage unit can be lifted and lowered independently with the integrated lifting unit. This way, several products can be stored one after another – that is into the depth –. This is best suited for varietal purity storage, as the first loading unit per channel (LIFO) is accessed first. Of course, the system also offers an automatic relocation (in the case of varietal impurity storage). Loading and unloading is always carried out from one side. The shuttle receives energy either from a trailing cable or through a battery, resp. power caps. Advantages at a glance: For the transport of euro pallets or other objects Lifting unit for loads up to 2.5 t Can also be used in pairs for heavier loads With power cable or equipped with own power supply Customer-specific shuttle planning and manufacturing No matter what requirements and needs you have: With these equipment options, you are always well prepared. In a personal conversation, we will surely find the right solution for you. Paper roll transport Bond 2x 2,5t. Diameter: 1.550mm Width: 2.250 mm Heavy load capacity Take advantage of a potential euro pallet load capacity of over 1.2 t. Euro-pallets For larger dimensions, up to 2.5 t and, used as pairs, up to max. 2 x 2.5 t are possible.
