Red LED AO000145

rectangularlightingLED

LED Surface area light, camera, 9,2x133x156mm, Polarity free red light, 660nm, 22-26V DC, Cable 4pin, IP65, Aluminum+PMMA including 4x Screw, 4x Nut, 4x Toothed washer Description LED lights - Additional lights for camera systems For any kind of inspection tasks with a camera sensor the lighting is essential, as only high-contrast images enable reproducible evaluations. Here the lighting has a decisive influence. The choice depends on different factors such as the distance to the test object, its size, the component criteria to be tested or the expected environmental conditions. Electrical features Betriebsspannung (DC) 21.6 - 26.4V Type of electrical connection Cable Short-circuit protection yes Reverse polarity protection yes Mechanical features Ambient temperature O - 50°C Width 15ômm Height 9,2mm Light field length 100mm Degree oi protection (IP) IP65 Housing material Alumlnum Optical features Wavelength oi the lamp ôôOnm Light source Polarity free red light Rated operating current 450mA Number of pins 4 Flash controller No Protection class III Number of cores 4 Light field width 100mm Length 133mm Design Cubold Front screen scattering behavior diffuse Front screen material PMMA Light version Surface area light
