Beam expander

Small, lightweight and easy-to-install, our BE beam expanders enlarge the beam diameter and optimally collimate your laser's output by 2.5x, 3x, 4x and 6x. The larger beam diameter reduces dangerous hot-spots and risk of optical damage during machine operation, especially in harsh operating environments. BE beam expanders are developed for higher power (>300 W) CO2 laser operation without water cooling. The BE outer diameter and connecting thread (M30x1) are consistent across the magnification options for easy integration. Features and Benefits • For collimation of CO2 laser beams. • Standard fixed magnifications from 2.5x, 3x, 4x and 6x. • Galilean telescope design reduces length of beam expander and avoids intermediate focus. • Adjustable divergence enables fine tuning of output beam collimation. • Ruggedly constructed BE beam expanders conveniently and easily mount to the front of Iradion Eternity and Infinity-series lasers for maximum adjustability and perfect alignment. • Interior optical surfaces of BE beam expanders are shielded from the operating environment. • BE series are a standard in the industry and were selected for their ideal balance of cost and performance. • Includes mounting ring and optional extender piece.
