Cartridge filter housing TIG/TIF series

for waterhigh-performance

Applications Secondary filtration, safety filtration. The disk filter allows high efficiency and filtration precision. Thanks to the excellent UV ray resistance, it can be installed outdoors without any protection. Materials • Body: polyamide reinforced with fibre glass • Cover: polyamide reinforced with fibre glass • Closure elements: - polyamide ring nut - ring in stainless steel AISI 304 • Filtering element: - mesh in stainless steel AISI 304 with polypropylene structure; - polypropylene disks. • Gaskets: NBR Characteristics • Maximum working pressure: 10 bar at 20° . • Standard filtration grade: 120 mesh (filtration available: 50, 80, 150, 200 mesh). • Types of connection: threaded, victaulic or combined. • Manometer coupling: Ø1/4’’ female. • Installation: on line or at right angle.
