Circular saw blade grinding machine KHF 100

CNCautomatic6-axis

When designing the machine, great importance was attached to simple and easy operability. It ensures short programming times and allows flexible deployment of the operating personnel. The machine is operated via a clear 15.1 inch touch screen with a Linux-based interface. 6 CNC-controlled axes guarantee complete machining of all common tooth geometries in just one pass The space-saving machine concept allows a high degree of ergonomics and excellent operability Automatic adjustment of all common angles and automatic detection of the Tooth pitch with built-in sensor technology on the feed pawl The positioned tooth can also be finished in several passes Easy access for maintenance work on control cabinet, coolant pump, pneumatics and extinguishing device Automatic grinding wheel probing by means of acoustic sensor Grinding wheel compensation integrated in the basic machine "LINUX Debian 10" control with multi-core processor Application programs Grinding-wheel feed is at the top. This process can be repeated several times Grinding-wheel feed is at the top and at the bottom what results in 2, 4 or 6 feeds Grinding-wheel feed is at the top. At the bottom, the grinding-wheel is moved back. The grinding head goes quickly upwards and the feed is again activated. This process can be repeated several times.
