Rotary arm wrapping machine 2500 B

automaticbagfor textiles

Line pallet wrapper is designed to keep the load immobile and wrap it with stretch film using a mechanical rotating arm. Arm Wrap 2500B is conceived to give the opportunity to keep the pallet still and to stabilize the product using a rotating arm. The machine is suited for medium/high production capacity and for unstable loads. It can be installed at the end of automatic production lines or as separated unit. It is available with infeed and outfeed roller conveyors. Motorizes prestretch system set at 250% with the possibility to interchange manually the pre-stretch ratios up to 300%.The touch screen ensures high flexibility and functionality: easy set up, fault detection and manual setting. The machine is also equipped with the claim, cutting and sealing unit and many other options. Available with safety guards, interlocked doors and infeed and outfeed safety barriers. Technical features: Machine structure in painted steel sheet Useful height 2000 mm Environmental humidity conditions: ≤ 90% Operating Temperature range: + 0° C to + 40 ° C Film cut and clamp system Film welding system by temperature controller Arm diameter 1700 mm Height conveyor 450 mm (custom made on request) Motorized pre-stretch set at 250% with possibility to interchange pre-stretch ratios (150, 200, 300%) Ermegency stop in compliance with CE regulations Machine controlled by PLC SIEMENS Film carriage fall protection system Acoustic wearning and lamp at the cycle start Inverter “Schneider” Color 7,2” user-friendly “Siemens” touch screen Contattors and button“Schneider” Sensors“ P + F” Pepperl+fuchs
