Ultrasonic flow meter IFX-M4-03

volumefor liquidsDN25 - 1"

The IFX-M4-03 ultrasonic energy meter has been used for measuring energy consumption for fluids, also other than water, in closed or open energy systems, and also for calculating the consumption of water. The instrument is designed to measure and record data in two separate registers for heating and cooling for the measurement of the flow rate from DN15 up to DN50 in a compact version. It can be used for the measurement of commercial energy consumption, for local or district heating systems, in the home environment, office buildings, centralized energy systems and similar projects. Description The ultrasonic energy meter IFX-M4-03, flow meters, energy meters, ultrasonic flowmeters, and industrial automation systems have been ISOIL Industria‘s passion and continuous research since 1958, and for any information or advice please do not hesitate to contact our specialists. Technical Specifications Temp. Measurement of the difference limits 2… 150 K or 3… 150 K Type of temperature sensors Pt500 DS (qp <= 6 m3 / h) or PL Connection diagram – two-wire, cables up to 5 m long. Internal data logger capacity with recording up to 960 hours per hour up to 1,116 days for daily records up to 36 months for monthly records External dimensions of the calculator 117 × 44 × 90 mm Integrated optical communication interfaces according to EN61107 (IEC 1107) available in M-bus plug-in modules; 2 pulse outputs; Wireless 868 MHz
