Characteristics

Operation
electric
Type
external
Product applications
industrial
Other characteristics
high-frequency, three-phase
Force

Min.: 6 kN

Max.: 14.6 kN

Rotational speed

6,000 rpm, 9,000 rpm
(37,699.1 rad.min-1, 56,548.7 rad.min-1)

Power

Min.: 500 W
(0.68 hp)

Max.: 4,000 W
(5.438 hp)

Description

Fixed frequency electric vibrators, suitable to be applied to systems and machines in the precasting industry and whenever a high fixed frequency vibration is requested. The ITVAF series electric vibrators with fixed vibration (6000 or 9000 rpm) provide a centrifugal force of up to 1480 Kgf (14,6 kN). They are available with either the fixed or cradle connection (RS types). CATEGORY EC Power supply Three-phase voltage from 24V to 690V at the various frequencies, depending on the type and series. Italvibras can supply variable frequency drive VIBRAVAR and different types of variable frequency equipments (CFV, MULTIVAR). Operation Continuous service (S1) at the maximum declared centrifugal force and electric power values. Centrifugal force Range extended up to 1480 kgf (14,8kN). Insulation class Class F (155°C).
