DC power supply IT-N6900

with USB outletbuilt-in2U

IT-N6900 DC power supply has 60V and 150V, 800W and 1500W output. It features as black panel and large screen, low ripple and noise. It can provide stable and pure DC power, two current ranges, up to 1μA current resolution. It has CC and CV priority settings, new Foldback protection. It is well used for the test of DC-DC, semiconductor lasers, automotive electronics, communication electronics, motors, PV modules and so on. IT-N6900 series supports SCPI and LabVIEW drivers, built-in USB/LAN/digital IO communication interface, optional GPIB/RS232, suitable for remote control and system integration, and can be used in R&D, production lines, univeristies, etc. IT-N6900 supports trend analysis function, allowing end users to observevoltage, current and power online for a long time. Users can save test datain U disk, and the time interval of data recording can be set, which isespecially suitable for long-term aging test of production lines or R&Dlaboratories. HD screen with graphic display, users can observe theabnormal situation of the test in real time. The LIST programming function of IT-N6900 Programmable DC Power Supply can provide a maximum of100s teps of sequence output , and a total of 10 sequence files can be edited.The user can generate various output change sequences by editing the steps suchas voltage, current, time and whether to cycle the steps of each single step.The parameters include time units. IT-N6900 Programmable DC Power Supply has CC/CV priority function, which is suitable forcomplex applications with high speed or no overshoot test requirements. In CV priority mode, you can get faster voltagerising.
