Panel fastener 0.0.388.91

clamping

For securing panel elements to Profiles 8 without the need for additional machining. Tightening the clamping screw fixes the Panel Clamp to both the panel element and the profile. Particularly suitable for attachment of unframed panels etc. Not suitable for mesh and corrugated mesh. The panel elements of thickness 4 - 10 mm can be clamped in position by the asymmetrical spacer washers. Depending on the particular application, it may be necessary to invert the spacer washers in the housing. Max. loading for each Panel Clamp without pinning. Fmax = 100 N Possible pinning position for securing the panel element against movement.
