Machine foot 0.0.719.15
metaladjustable

Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable - image - 2
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable - image - 3
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable - image - 4
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable - image - 5
Machine foot - 0.0.719.15 - item industrial applications - metal / adjustable - image - 6
Add to favorites
Compare this product


Characteristics

Applications
machine
Material
metal
Type
adjustable
Diameter

28 mm
(1 in)

Description

Adjustable Foot 8 M20x40 is extremely strong and features a 40 mm stepless height adjustment mechanism. Its integrated flange can be used to fasten it to a Line 8 groove. To fasten the product in this way, a through hole needs to be drilled through the profile, which itself must be at least 80 mm tall. Screw Anchor ST 8x130 (0.0.720.66) is used to create the floor fixing. Assembly Instructions Installation sequence for Adjustable Foot 8 M20x40 and Screw Anchor when using profiles that are 40 mm wide: 1. Drill ⌀24 mm through hole (from both sides, if necessary) 2. Insert and fasten Adjustable Foot 3. Use hex key to level frame from above 4. Drill hole in floor and clear out hole 5. Introduce Screw Anchor from above and tighten securely in place
