EtherCAT communication module FRC-EP190

CANEthernet

The FRC-EP190 comes with a variety of different automotive communication interfaces plus an optional EtherCAT slave interface. It is ideal for applications in which several bus systems are to be merged into a single device with its own processing power – e.g. for logging, gateway and residual bus simulation applications. All applications run on the device, a PC is only needed for configuration or stimulation/visualization of data, as the actual intelligence – for e.g. the transport protocols – is outsourced to the embedded platform. HMS provides with Ixxat ACT (Advanced Configuration Tool) an easy to use Windows-based tool enabling customers to configure the device via drag-&-drop. HIGHLIGHTS FlexRay option Industrial Ethernet support (like EtherCAT) Up to 8 CAN (FD) channels in one device Only a few µs delay of frames in classical gateway applications Analog inputs Up to 2 kV galvanic isolation Compatible to the Ixxat CAN@net Generic Ethernet Protocol
