Main Features
AISI 304 SS FRAME
AISI 316 SS Filling Parts (Compliance with international sanitary regulations)
PLC Touch Sensitive Screen
High Accuracy Volumetric Filling
Compliance with CE Standards
Mechanic Working Principle
production capacity: 1500 – 2500 bottles/hour
for plastic and glass bottles
filling volume :100 – 1100ml
System of filling : Volumetric + pneumatic
System of nozzle : nozzles are closed from the inside
Owrking pressure : 6 Bar
Working voltage : 220 Volt / 50 Hz
Control voltage :24 V DC
Control unit : PLC
Cap feeding : feed with vibration system for various bottles
Capping unit : It has special mold for various bottles and pneumatic system .
Cap screwing unit : Fiam pneumatic engine
Width of conveyor: its size changeable for different bottles (90-300mm)
Capacity: 3500 – 30000 Bottle / hour (for 500 ml volume bottle)
Products : Water, Milk, Non-carbonated drinks,
