Ball valve with handwheelhigh-pressure
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- with handwheel
- Other characteristics
- high-pressure
- Pressure
Min.: 2,000 psi
Max.: 20,000 psi
- Temperature
Min.: -46 °C
(-51 °F)Max.: 121 °C
(250 °F)
Description
• The valve switch transmission adopts the ball screw structure, effectively reduce the operating torque and achieve common valve 1/3.
• Gate valve structure
• Valve with tail stem which has pressure balance and switch indicator
• It is supply for big diameter high-pressure valve structure.
• Working pressure ：2000PSI～20000PSI
• nominal bore ：1.13/16～9（46mm～230mm）
• working medium : oil , nature gas , mud , consist of H2S CO2gas • working temp.：-46°C～121°C（LU class ）
• material ：AA、BB、CC、DD、EE、FF、HH
• PSL：PSL1～4
• PR：PR1～2
