Laser engraving machine CK3030

woodmetalbrass

1.high accuracy ball bearing guide screw of taiwan,minimize the slit. 2.imported linear rail,self lubricating glide. 3.our routers have the features of recarving after stop and the power failure may be restored. 4.unique preservation way of the zero point. 5.use for long time and no distortion. 6.this type is suitable for advertisement,PCB milling. Machine Body Whole cast iron Body Dimensions 600x600x600mm Z-axis Working Area 45mm Max. Feeing Height 60mm or bigger Cut Thickness of Material <20mm Max. Speed 4,200mm/min Working Speed 0-3,000mm/min Mechanical Precision 0.01mm Software Type3, Artcut, Artcam Max. Power Consumption 900W Power Supply AC220V/50Hz and others Driver Type Step Motor Memory 1MB Spindle 1.2KW variable speed, water cooled motor Spindle Speed 0-24,000rpm Blade Diameter 1-6m Control System Artcut or Weihong (NCSTUDIO) or DSP(USB interface Command G code, u00, mmg, plt Interface RS232 Running Circumstance Temperature 0-45 Relative Humidity 30%-75%
