Gas rotary union LPT080-0220-05S-01Afor the gas industryaluminumwith slip ring
Add to favorites
Compare this product
Characteristics
- Medium
- for gas
- Applications
- for the gas industry
- Material
- aluminum
- Other characteristics
- with slip ring
- Rotational speed
Max.: 100 rpm
(628.32 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Nominal size
Max.: 8 mm
(0.315 in)Min.: 0 mm
(0 in)
Description
Part Number: LPT080-0220-05S-01A
Circuits: 2 circuits * 20A, 5 circuits *Device Net Signal, 1circuit *Compressed Air
Working Voltage: 24VAC/220VAC
Dielectric Strength: Between circuits1000V@50Hz(P)
500V@50Hz(S)
Insulation: ≥500MΩ@500VDC (P)
≥300MΩ@300VDC (S)
Electrical Noise：≤70mΩ (50rpm)
Working Speed：0~100 rpm
Through Hole：φ80mm
Contact：Precious Metal
Housing：Aluminum Alloy
Wire Size：MULTI-STANDARD/SC2.1(2.5mm²) UNITRONIC@BUS DN THIN FD
P1x2XAWG24+1x2XAWG22
Temperature: -20°C~+60°C
Humidity: ≤60%RH
IP64
Pipe Diameter: 8mm
Rotating Torque: ≤5 N.m
Connecting Aperture: G1/B
