Through-hole electrical slip ring LPT038-1205

The LPT038-1205 through bore slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. The part is LPT038 series slip ring that has a hole of φ38.1mm. It cn transmit 5A current in 6 circuits. Adopting advanced fiber brush technology, the part has a reliable performance with stable conatct and good conductivity. Specification Circuits - 12 Current Rating - 5A Voltage - 240 VAC/DC Dielectric Strength ≥1000V@50Hz between circuits Insulation - ≥500MΩ@500VDC Hole Diameter - 38.1 mm Working Speed - 0~300 RPM Contact - Precious metal Housing - Aluminum alloy Working Temperature - -20~+60℃ Humidity - ≤60%RH Protection Grade - IP54
