Press-fit end cap JJEC series

roundstainless steelfor tubes

This series of products are necessary supporting products for pipe and pipe fittings with internal pressure resistance, hydraulic instantaneous blasting and pipe suitability pressure test. There are A type, B type, inner seal, outer seal and other specifications and models, which are suitable for port sealing of pipes and fittings such as solid wall, structural wall and metal composite of different sizes. The end seals of pipes and pipe fittings are patented products of our company. They are made of 304 stainless steel and high-quality carbon steel. They have simple structure, convenient operation, good sealing performance, high strength, light weight and corrosion resistance. Features 1. φ10～φ800 are processed by precision casting, φ900～φ1600 are mechanical head, and the seal adopts A-type radial sealing structure, all materials are made of high-quality stainless steel, and the outer surface of the fixture parts is uniform in stainless steel, with high strength and corrosion resistance. 2.The Endcap is a patented product with simple structure and convenient operation. During the test, the process flow of first loading the card and then sealing is realized to ensure that the sealing of the card is 100% leak-free. 3. There is no need for special mounting brackets when assembling the Endcap, and safety hoisting devices are available for parts above 3kg. 4. The split-type clamping block structure can realize automatic centering and make the pipe fittings more firmly clamped; the clamping block is designed as a hollow structure, which is light in weight and easy to handle and assemble while ensuring the strength.
