PP extruder JWM series
for PETfor PA66spinning

PP extruder
PP extruder
PP extruder
Add to favorites
Compare this product


Characteristics

Treated material
for PP, for PET, for PA66
Other characteristics
spinning
Output

Max.: 1,050 kg/h
(2,314.8538 lb/h)

Min.: 4 kg/h
(8.8185 lb/h)

Screw diameter

Max.: 200 mm
(7.9 in)

Min.: 20 mm
(0.8 in)

Maximum speed

Max.: 90 rpm
(565 rad.min-1)

Min.: 20 rpm
(126 rad.min-1)

Power

Max.: 220 kW
(299.12 hp)

Min.: 2.2 kW
(2.99 hp)

Description

JWM series extruders are used for melt spining of PET, PA6, PA66, PPchips.We have huge turnover every year because of dozen years ofexperience and advanced technology, and there are thousands of extruders running well in more than 700 spinning and non-woven plants.The LTM designed in screw,and the melt quality is better. The precision ofscrew and barrel is higher after professional processing. And equiped highprecision bevel-teeth gear box, operating stability, lowest noise. assemblestrong push bearing. in order to guarantee bearing huge axle power. and be able to select to equip imported high speed bearing and seal parts.
