Multitouch screen panel PC IVS-215 series

LCDPCAP capacitive touch screenLED backlight

The IVS-215 is a high-performance integrated industrial panel PC featuring a 21.5-inch LED backlight display with 1920x1080 resolution and 10-point multi-touch support. It is powered by Intel® Elkhart Lake or Alder Lake-U/H110 platforms, offering multiple processor options, configurable up to Intel® Core™ i7. The device provides a wide range of interfaces, including multiple USB 3.0/3.2 ports, Gigabit Ethernet, and COM ports, while supporting WiFi 6 and 4G/5G expansion. With a 12-36V wide voltage input design and multiple protection features, the front panel is rated IP65, making it suitable for various industrial scenarios. Core Count/Thread Count 4/4 2P+4E 2P+8E Base Frequency 2.00 GHz 1.2 GHz 1.3 GHz 1.7 GHz Turbo Frequency - 2.60 GHz 4.4 GHz 4.7 GHz Smart Cache - 1.5 - 10 - 12 TDP 10W 15W Network - 1x Intel I210AT,1 x Intel I226-v 3 x Intel I226-V, 1 x Intel I210AT Ethernet port (4 Ethernet ports optional with POE motherboard) I/O Interfaces Aspect Ratio - 16:9 Luminance 220 cd/m2 Contrast Ratio - 1000:1 Backlight Life 30000 h Angle of View - 89 (left), 89 (right), 89 (top), 89 (bottom) Touch Screen Type - 10-point capacitive screen Luminousness - Above 81% (resistive screen > 80%) Lifespan 50 million touches (resistive single point 10 million touches) Weight TBD Environment Operating Temperature（OP） - 0 ~ 50 ℃(32~122 ℉) Operating Relative Humidity 95% @ 40 ℃ (non-condensing) Storage Temperature (NOP) -20 ~ 60 ℃ (-4 ~ 140 ℉) Shock Resistance (OP) 15g 11ms half-sine wave Vibration Resistance (OP) 5~500Hz 1Grms EMC CE Class A
