3-axis CNC machining center KMC-1100V

universalhigh-precision

High rigid construction four slideways on base, ensures high precision machining accuracy. A 11 kw / 15 kw (15 HP / 20 HP) spindle motor with 2-step gear transmission provide a high revolution up to 4400 rpm. The spindle is supported by grease packed precise angular contact ball bearing to minimize heat generation. The lubricant for both spindle and the gear box is forced-cooled by the standard oil cooling system to ensure protection from thermal displacement. The 24-station rotary-type tool magazine is driven by a cam unit (KMC-1100V) The 32-station chain-type tool magazine is driven by an electric motor (KMC-1500V) An universal angle head (optional) can widely extend machining application.
