O-ring seal K75 seriescircularsynthetic fiberresin
Add to favorites
Compare this product
Characteristics
- Type
- O-ring
- Configuration
- circular
- Material
- synthetic fiber, resin
- Application
- piston, for piston rods, guide, rod
- Other characteristics
- hydraulic, pneumatic
- Temperature limit
Max.: 130 °C
(266 °F)Min.: -40 °C
(-40 °F)- Diameter
Max.: 392 mm
(15.433 in)Min.: 25 mm
(0.984 in)- Outer diameter
Max.: 400 mm
(15.748 in)Min.: 30 mm
(1.181 in)- Speed
1 m/s
(3.3 ft/s)
Description
K75 piston-rod guide rings are composite guiding elements, produced from syntetic fabric and phenolic resin which provides high load carrying capacity designed to be used in rod and piston applications in hydraulic systems.
Advantages
• Low coefficient of friction
• High Load bearing capacity
• The high form stability at operating temperature range
• Low swelling
• Wide range of dimensions
Area of Application
• Mobile machinery
• Mining industry
• Excavators
• Presses
• Heavy duty cylinders
