Rotary disconnect switch KU 430UL98low-voltage4-poleAC
Add to favorites
Compare this product
Characteristics
- Type
- rotary
- Voltage level
- low-voltage
- Number of poles
- 4-pole
- Electrical characteristics
- AC
- Construction
- modular
- Certifications
- UL98
- Primary current
30 A
- VAC
240 V, 480 V, 600 V
Description
• Lockable to off-position
• Switching speed is independent of the operator
• Silver contacts ensure safe and durable operation
• Suitable for use on a circuit capable of delivering 50kA rms symmetrical, 600 Vac when protected by Class J fuse.
• Change-over switches consist of two 3- or 4-pole switches. Marked with CO.
Weight (lb/kg) - 0.99 / 0.45
Wire Size (Cu Only) - 14-1/0 AWG
Catalogs
No catalogs are available for this product.
See all of KATKO‘s catalogs
