Diaphragm valve 135 01 serieswith handwheelstopfor water
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- with handwheel
- Function
- stop
- Media
- for water
- Body
- flange, seat, EPDM, metal, plastic
- Applications
- parts, shaft
- Other characteristics
- ISO, DIN, corrosion-resistant
- DN
Max.: 100 mm
(3.937 in)Min.: 25 mm
(0.984 in)- Pressure
16 bar
(232.1 psi)- Temperature
Max.: 110 °C
(230 °F)Min.: 0 °C
(32 °F)- Flow rate
Max.: 240 m³/h
(8,475.52 ft³/h)Min.: 24.2 m³/h
(854.61 ft³/h)
Description
wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water
10 year warranty
maintenance-free shaft sealing with self-lubricating EPDM lip gasket, replaceable under pressure up to DN 80
EPDM-seat gasket
cone rotatable, protected against water hammer
flange connection
without drain port (drain valve cannot be added)
spindle thread not in contact with medium
with a black handwheel
free from dead spots
Open position indicator
Standards and Approvals
DVGW approval up to DN 80
WRAS approval
KIWA approval up to DN 100
VA approval
plastic parts with KTW and W 270 approval
according to accepted materials list from German environmental agency
up to DN 32 soundproofing certification according to DIN EN ISO 3822 Class 1
DIN EN 1213 / DIN EN 558-1
ÜA-Reg.-Nr. R-15.2.3-21-17048, WIEN-ZERT
