Diaphragm valve 143 22 series
hydraulicdistributiondrain

Diaphragm valve - 143 22 series - Kemper Olpe GmbH - hydraulic / distribution / drain
Diaphragm valve - 143 22 series - Kemper Olpe GmbH - hydraulic / distribution / drain
Diaphragm valve - 143 22 series - Kemper Olpe GmbH - hydraulic / distribution / drain - image - 2
Add to favorites
Compare this product


Characteristics

Type
diaphragm
Operation
hydraulic
Function
distribution, drain
Body
seat, PTFE, metal, plastic
Applications
parts
Associated function
balancing
Other characteristics
DIN, corrosion-resistant, thermal
DN

15 mm, 20 mm
(0.591 in, 0.787 in)

Pressure

16 bar
(232.1 psi)

Temperature

Max.: 90 °C
(194 °F)

Min.: 50 °C
(122 °F)

Flow rate

1.3 m³/h, 1.6 m³/h
(45.91 ft³/h, 56.5 ft³/h)

Description

thermostatic balancing valve for hydraulic balancing of riser and distribution pipes for hydraulic balancing of hot water return systems (PWH-C), supports thermal disinfection wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water isolating unit with temperature sensor pocket PTFE seat gasket thermostatic balancing unit press connection for Geberit MAPRESS pipe with plugged drain port free from dead spots with isolating, balancing and pre-setting function Standards and Approvals DVGW approval ÖVGW approval SVGW approval KIWA approval plastic parts with KTW and W 270 approval for systems according to DVGW worksheet W 551 / W 553 / DIN 1988-300 according to accepted materials list from German environmental agency ÜA-Reg.-Nr. R-15.2.3-21-17048, WIEN-ZERT
