Worm gear reducer 4747, 4749, 4751, 4755

right anglehollow-shaft1 - 5 Nm

Worm gear Input broad side 4747 ... 4755 Compact, universally usable and maintenance-free worm gearbox in a size with an axle distance of 14 mm and various reduction ratios. The drive is located on the wide side of the gearbox. The worm wheel assembly is right-handed. The direction of rotation on the shaft is arbitrary. The gearbox is characterised by a compact design with maximum torque, sturdiness and smooth power transmission. Simple mounting is made possible by a flexible screw fixing. Special features Maintenance-free grease lubrication Case hardened worm and cog wheel Housing made of zinc die-casting Special model with bronze bearing Size 42 x 35 x 17 mm 6 ratios as standard On request other ratios are possible Axial distance 14 mm Input / Output hex 6 mm On request also possible with counterclockwise- ascending worm and wheel set
