Motor soft starter 2 - 22 kW | LEKTROMIK ® E series

electronicwith integrated injection brake

Electronic controllers Soft start, soft stop and brake for three-phase induction motors Features ¨ Electronic d.c. injection brake with a short delay time can be integrated in controller ¨ Compact unit easily retrofitted ¨ Shutdown on detection of phase failure during ramp up ¨ Controller inhibited when phase sequence is incorrect (E2, E4) ¨ Version for operation with two phase sequences for reversing drives available (E22, E42) ¨ Auxiliary module (Option I1) allows: - Soft start with current limit - Switch-on torque pulse - Monitoring of power with overload trip - Improvement of power factor at low load
