KF932 IEC61850 Relay Test Set Item No.: 203006 The most light and powerful handheld digital relay tester for IEC61850 testing; Applied to digital protection relay, Measure & control device, IEC61850 Complying IEDs ,Merge Unit and substation control system testing and detection; Touch screen and keypad, to meet different using habits. 4400mAh large capacity lithium battery, continuous work for more than 10 hours. Small size, easy to portable. Basic Functions ● - KF932 IEC61850 Relay Tester is developed based on the intelligent substation related standards to analyze the SV, GOOSE, IRIG-B and IEEE1588 message, calculate the magnitude, phase and frequency of voltage and current, and real-time monitor of GOOSE virtual terminal. ● - Receiving closed-loop testing of smart devices via SV, GOOSE message sending, subscription and publication of GOOSE messages; ● - Phase detection function is achieved by analyzing and calculating different control blocks; Binary input and output of the hard contact can be completed on the intelligent operation box transmission delay and SOE on the accuracy of the measurement; ● - SV and GOOSE exception statistics analysis and synchronization function to achieve the integration of the unit discrete, lost frame and absolute delay measurement. ● - With small size, touch screen operation of the convenience and powerful measurement and analysis and testing capabilities, greatly to meet the intelligent substation operation, maintenance and debugging of the protection, monitoring and control devices, IEC61850 complying IEDs, the merger unit and the station control system Detection and commissioning requirements.
