Manual winch Riverina

wire ropehandlingdouble-drum

HyQuest Solutions’ Riverina winch is a hand-operated double drum winch capable of handling gauging weights up to 100 kg (220 lb). The design shows two main advantages: Firstly, it enables the operator to change from sounding mode to traversing mode very quickly by engaging the drive gears on each drum. Secondly, the double drum concept eases traversing, as the forces exerted by the gauging weight are largely cancelled out. The winch can be used on small travellerways up to 125 m (410 ft) span. The winch is designed for ease of operation and serviceability in the field: robust, portable, and operated easily and safely by one person. Special attention is paid to safety: An automatic Weston Brake locks the drum if the handle is released. This holds the load in any position - for safe and smooth sounding operation. HyQuest Solutions’ winches are equipped with Amergraph cables. The special construction combines two purposes: They permit the suspension in the stream of the current meter and heavy Columbus weights and at the same time they are the medium for carrying the meter signals to a counting device. The winches’ counters are protected within the frame and can be ordered to display either metric or imperial counts. Use with current meter Some elaborate features support current metering: A silver-plated slip ring conducts the signal from the sounding drum to the current meter counter. The counter can be installed at the winch itself, i.e. close to the winch operator instead of deep in the water at the current meter. The single layer of the signal cable on the drum prevents damage of the internal conductor and premature replacement.
