Tension/compression force sensor 9132CD19ringsingle-axispiezoelectric
Add to favorites
Compare this product
Characteristics
- Type
- tension/compression
- Form
- ring
- Number of axes
- single-axis
- Technology
- piezoelectric
- Applications
- calibration
- Other characteristics
- small, high-sensitivity, IP65, calibrated
- Rated force
Max.: 2.7 kN
Min.: 0 kN
- Height
3 mm
(0.12 in)
Description
• Sensitivity: ≈ –35 pC/N
• Dimensions DxdxH: 12x4.1x3 mm
• Connector: KIAG 10-32 pos.
Cable length: customized from 0.1 m to 3 m
Preloaded sensor
No
Mechanical properties
Axial stiffness
1.9 kN/μm
Bending stiffness
0.197 kN·m/°
Shear stiffness
0.6 kN/μm
Torsional stiffness
0.226 kN·m/°
Metrological characteristics
Linearity
±1 %FSO
Relative standard deviation of repeatability
0.06 %FSO
