Charge amplifier 5030A3measuringanaloglinear
Add to favorites
Compare this product
Characteristics
- Type
- charge
- Secondary function
- measuring
- Other characteristics
- analog, linear, rugged, single-channel, piezo, device manufacturing, for process monitoring, compact, miniature
- Voltage
-10 V, 10 V
- Current
Min.: 0 mA
Max.: 1 mA
- Frequency
Min.: 0 kHz
Max.: 10 kHz
Description
• Measuring range 1: ±100000 pC, measuring range 2: ±10000 pC
• Charge input: KIAG 10-32 neg.
• output signal: ±10 V with up to 10 kHz bandwidth
Metrological characteristics
Linearity
<±0.05 %FSO
Electrical properties
Output signal type
Analog, Voltage
Input type
Charge (Piezoelectric, PE)
Dynamical properties
Time constant
Long
