Ethernet expansion module K3840AS

• Digital input module • Adjustable sample rate up to 100 kHz • 16 digital channels, galvanically isolated in two groups The Stationary KiDAU Digital Input Type K3840AS is an expansion module for the Stationary System Base Unit Type K3800AS. The Stationary KiDAU Digital Input has 16 digital inputs thatare galvanicly isolated in two groups with 8 inputs each. The maximum sampling rate is 100 kHz. The device can store datafor a 1 800 s cycle at a sampling rate of 100 kHz which allowsthe user to start recording data before the test is actually started. This ensures that the measuring system works correct lyand prevents data loss. The trigger point is registered and recorded as in previous systems. An uninterrupted power supply is not needed to retain the data because flash-EEPROMs areused for the memory.
