Ball valve K740

leversamplingthreaded

INTEC K740 Sampling device ball valve, ball bore 40mm, sample volumen per switch 40/50/70 ml, soft seated. Features DN 15 - DN 200 soft seated floating ball sample volume per switch 40 ml, 50 ml, 70 ml ball bore 40mm FTF dimensions acc. to EN 558, GR.1 and EN 558, GR.27 flanges acc. to EN 1092 connection thread for sample bottle acc. to DIN 168 GL 25, GL 32, GL 45 full bore INTEC K700 - Sampling Device Ball Valves Sampling device ball valve of the modular INTEC system technology! This assembling device ball valve owned an extremely big outlet with pressure relief of the sampling flask. The sealing systems and also the body materials can be designed acc. to medium requirements. This sampling device unit is available for plant lines from DN15 up to DN200. Cavity filler design is available. Flask connection with thread acc. to DIN 168 or spring loaded disk is possible. Product Advantages Equipped with all advantages of the series INTEC K200 Extremely big outlet Sealing systems and body materials can be designed acc. to medium requirements Cavity filler design is available Bottle connection with thread acc. to DIN 168 or with spring loaded disk Various threaded connections on request Accessories Heating jacket Hand lever extension Stem extension Block unit - padlock unit Grid unit
