Piston valve KVN

pneumaticregulatingfor steam

KLINGER KVN DN65-150 Piston valves, flange design. Features DN 65 - DN 150 piston valve valve rings KX-GT piston made of special niro-steel FTF dimensions acc. to EN 558, GR.1 flanges acc. to EN 1092 Due to constant technical product improvement, KLINGER is the leading manufacturer of piston valves. Different types of connections (flange, threaded, butt and socket weld ends) and piston valves produced according to DIN and ANSI standards complete the wide product range of KLINGER's industrial valves. Product Advantages Reliably tight in the bore and to atmosphere in accordance with EN 12266-1 – leakage rate A Suitable for steam condensate-alternating operation as well as temperature shock operations High durability (operating cycles) Sensitive to sedimentations and vibrations Self cleaning due to construction design No erosion on sealing surface Revisable without requiring removal from pipe system Maintenance-free Accessories Actuators (electro mechanical, pneumatic) Special Designs Regulating piston valve DN15 - DN50 with regulation piston Regulating piston valve DN65 - DN200 with regulation lantern bush Certificates and Approvals Fire-Safe tested Type-test approval acc. to VdTÜV 1065 Release for oxygen service Successfully emission tested acc. to the requirements of TA-LUFT
