Planetary gear reducer MLX,MLXSD,MLXSS series

bevelright anglefor milling machines

FEATURES: 1. Bevel and planetary gears carburizing, quenching, grinding, gear profile modification, crack detection process, and gear tooth root shot blasting treatment. Optimized gears meshing accuracy, lower noise, and high efficiency 2. Gearbox and planetary frame are analyzed by FEM and optimally designed, in order to ensure less deformation during operation process, and more stable operation 3. Secured manufacturing quality and higher reliability 4. Customizable sizes and configurations according to the requirements PARAMETERS: MLX Series: Rated Power: P=50kW~4000kW Ratio: Maximum i=50 Models: MLX5~MLX500 Input Shaft Diameter: 65~250mm Input Shaft Center Height: 260~1100mm Mounting Circular Disc Diameter: 980~3850mm MLXSD Series Rated Power: P=1400kW~7000kW Ratio: Maximum i=65 MLXSS Series Rated Power: P=2000kW~9000kW Ratio: Maximum i=80 Rated Power:50kW~9000kW Ratio: Maximum i=80 Gearset: Bevel & Planetary Gears Shafts Position: Right Angle Mounted: Vertical Mounting Housing: Cast Iron APPLICATIONS: Vertical Mills, Cement Mills, Coal Mills Applied to raw material grinders Applied to crush coal sheets in the coal industry Applied to crush limestone, cement clinker, slag, lime, gypsum, coal ash, and ores in building and mine industry INSTALLATION: Vertical Mounting, Circular Disc is Connected to Millstone
