Plasma cutting machine Jet TrueCut 2040 H

for metalCNChigh-power

The machines of the Plasma-Jet TrueCut H-series are highly specialized cutting systems for the production or individual production of complex parts. This series is designed for high loads in multi-shift operation and is equipped with the latest Hypertherm technology and high-quality components.The extensive optional equipment enables versatile, tailor-made solutions for specific customer requirements. For example with several torches, oxy-fuel cutting heads, miter cuts or pipe processing units. Independent table for high accuracy Powerful ProNest LT nesting software for optimised production Customised for the use of HYPERTHERM plasma sources (option) Extensive options for customised solutions Construction Stand-alone cutter table features rigid steel construction for high load capacity Stand-alone table eliminates thermal and mechanical influences on the plasma cutter system Table is prepared for dust collection system, being equipped with electro-pneumatically actuated suction flaps for an efficient fume extraction of the segment where the cutting process is momentary in action Transmission and drives Dynamic AC servo drives from Panasonic on all axes with maintenance-free, zero-backlash planetary gears Low-wear and low-maintenance helical gears are designed for continuous operation Linear guide ways from on all axes, designed for long life and smooth motion even at high speeds. The width of linear guides on X/Y axes is 20/30 mm The structure of the machine and the selection of components are designed to enable multi-shift operation Cutting head Z axis with ball screw transmission and servo-driven automatic torch height control
