The machines of the Plasma-Jet TrueCut H-series are highly specialized cutting systems for the production or individual production of complex parts. This series is designed for high loads in multi-shift operation and is equipped with the latest Hypertherm technology and high-quality components.The extensive optional equipment enables versatile, tailor-made solutions for specific customer requirements. For example with several torches, oxy-fuel cutting heads, miter cuts or pipe processing units.
Independent table for high accuracy
Powerful ProNest LT nesting software for optimised production
Customised for the use of HYPERTHERM plasma sources (option)
High productivity, designed for multi-shift operation
Extensive options for customised solutions
Construction
Stand-alone cutter table features rigid steel construction for high load capacity
Stand-alone table eliminates thermal and mechanical influences on the plasma cutter system
Table is prepared for dust collection system, being equipped with electro-pneumatically actuated suction flaps for an efficient fume extraction of the segment where the cutting process is momentary in action
Transmission and drives
Dynamic AC servo drives from Panasonic on all axes with maintenance-free, zero-backlash planetary gears
Low-wear and low-maintenance helical gears are designed for continuous operation
Linear guide ways from on all axes, designed for long life and smooth motion even at high speeds. The width of linear guides on X/Y axes is 20/30 mm
The structure of the machine and the selection of components are designed to enable multi-shift operation
