3-axis CNC machining center VECTOR 1400 M SI
verticalcolumn typeSK40

3-axis CNC machining center - VECTOR 1400 M SI - Knuth Machine Tools - vertical / column type / SK40
3-axis CNC machining center - VECTOR 1400 M SI - Knuth Machine Tools - vertical / column type / SK40
Add to favorites
Compare this product

Characteristics

Number of axes
3-axis
Spindle orientation
vertical
Structure
column type
Spindle mount
SK40
Number of tool stations
24 tools
Other characteristics
high-precision
X travel

1,400 mm
(55.12 in)

Y travel

720 mm
(28.35 in)

Z travel

700 mm
(27.56 in)

Rotational speed

10,000 rpm
(62,832 rad.min-1)

Power

17 kW
(23.11 hp)

Work feed X-axis

Max.: 10,000 mm/min
(6.56 in/s)

Min.: 10 mm/min
(0.01 in/s)

Work feed Y-axis

Max.: 10,000 mm/min
(6.56 in/s)

Min.: 10 mm/min
(0.01 in/s)

Work feed Z-axis

Max.: 10,000 mm/min
(6.56 in/s)

Min.: 10 mm/min
(0.01 in/s)

Table load capacity

1,500 kg
(3,307 lb)

Positioning accuracy

0.005 mm
(0.0002 in)

Repeatability

0.003 mm
(0.00012 in)

Weight

9,500 kg
(20,943.91 lb)

Overall length

3.8 m
(12'05" )

Overall width

2.6 m
(8'06" )

Overall height

3.3 m
(10'09" )

Description

The Vector 1300/1400 series is the perfect solution for machining very large and heavy workpieces. The innovative design of the machine base made of high-quality Meehanite casting with a low center of gravity, and the use of only the highest quality components guarantee the consistently high precision even in multi-shift production. Thanks to a wide range of accessories, the machining centers become a tailor-made complete solution for specific applications. KNUTH also offer automation solutions for this series, with which you can increase your productivity even more. Available with Siemens or Heidenhain controller Spindle on multiple bearings ensures minimal vibrations 30-bar CTS to ensure optimum machining quality Designed for multi-shift operation Many customization and automation possibilities The large VECTOR Series is perfectly equipped for large jobs and can be ordered with customized accessories to provide flexible solutions for constantly expanding requirements Machine Design The extra-wide column base and large guide distances ensure the necessary rigidity for fast machining processes requiring high precision During the development of this series, modern FEM analysis tools were used for the simulation of countless load conditions in order to guarantee superior stability of the machine frame in real-world applications, which now exceeds all expectations for this class of machines All axes move on premium, fully enclosed linear roller guideways and precision ball screws and are driven by dynamic servo-motors Spindle Main spindle runs on multiple bearings to ensure excellent absorption and dissipation of forces during machining
