Band sawing machine ABS 380 L

horizontalfor metalsfully-automatic

The models of the ABS-L series are fully automatic horizontal band saws for precisely straight sawing of large and heavy workpieces. A rigid dual column frame forms the heart of the extremely stable construction. Using the central control panel, you can regulate the saw frame feed, steplessly adjust the saw blade speed and machine the workpiece hydraulically. The robust automatic material feed does not need any electronics or programming and still offers high repeat and dimensional accuracy. Material feed system with workpiece guide rollers Hydraulic workpiece clamping Optical detection of the workpiece height Feed roller table 1,2 m Cutting Capacities Cutting capacity 0° (flat) (length x width) - 430 mm x 380 mm Cutting capacity 0° (square) - 380 mm Cutting speed infinitely variable - 20 m/min - 100 m/min Stop length - 500 mm Accuracy of the feeding - 0,5 mm Torsionally rigid machine frame made of a robust steel construction with high-quality linear guides Proven material feed system with hardened workpiece guide rollers and hydraulic workpiece clamping Shorter machining times are made possible by an advanced hydraulic saw frame feed design, including a new pressure control system to master any sawing tasks - infinitely variable setting of feed speed and cutting pressure All required settings are accessible and clearly labeled at the second control valve for easy adjustments Optical registration of the workpiece height allows empty runs in rapid feed mode for an optimum change-over to work feed and limiting of the vertical saw frame travel - everything is automated to reduce operator work load
