Crane Boom
Max. Lifting Capacity: - 100 t x 3.6 m / 90 t × 3.9 m
Max. Length: - 61.0 m
Main & Aux. Winch
Max. Line Speed: - 120 m/min (1st layer)
Rated Line Pull (Single Line): - 112 kN {11.4 tf}
Wire Rope Diameter: - 26 mm
Wire Rope Length: - 240 m (Main), 165 m (Aux)
Brake Type: - Wet-type multiple disc brake (Optional)
Working Speed
Swing Speed: - 4.0 min-1 {rpm}
Travel Speed: - 1.7 / 1.1 km/h
Weight
Operating Weight: - 90.3 t
Ground Pressure: - 101.8 kPa
Counterweight: - 31,900 kg
Transport Weight: - 41,280 kg
Fixed Jib
Max. Lifting Capacity: - 10.9 t × 18.0 m
Max. Combination: - 51.8 m + 18.3 m
Power Plant
Model: - ISUZU 6HK1
Engine Output: - 210 kW / 1,900 min-1
Fuel Tank Capacity: - 400 liters
Hydraulic System
Main Pumps: - 3 variable displacement
Max. Pressure: - 31.9 MPa {325 kgf/cm2}
Hydraulic Tank Capacity: - 375 liters
