VOCs free water based wave soldering flux
JS-3000V-3
Easier management being non-dangerous goods
By using pure water instead of IPA, JS-3000V-3 completely removed VOCs. There is no handling regulation for JS-3000V-3 as dangerous goods in international transportations or storage, which reduces transportation costs and opens up dangerous goods storage room.
olved problems of water-based flux
Special resin is added to improve the poor drying speed of water-based flux. Effectively reduces solder scattering, loss of flux, and resultant non-soldering and bridging.
Ultra-low residue for a beautiful finish
JS-3000V-3 uses a combination of solids such as rosin and special resin. As a result, flux residue after soldering is hardly visible. Achieves a low-residue non-sticky beautiful finish.
Product Performance Table
Product Name - JS-3000V-3
Product Category - Liquid Flux for Wave / Selective Soldering
Solid Content(%) - 5.0
Specific gravity (at 20℃) - 1.015
Halide content(%) - 0
Flux Type - ORL0 (IPC-J-STD-004A)
Application - Spray
Purpose of Use - Wave soldering
Characteristics - VOCs Content 0%
