Digital luminance and colour meter CS-160
compactUSB

Digital luminance and colour meter - CS-160 - Konica Minolta Sensing Americas - compact / USB
Digital luminance and colour meter - CS-160 - Konica Minolta Sensing Americas - compact / USB
Digital luminance and colour meter - CS-160 - Konica Minolta Sensing Americas - compact / USB - image - 2
Digital luminance and colour meter - CS-160 - Konica Minolta Sensing Americas - compact / USB - image - 3
Digital luminance and colour meter - CS-160 - Konica Minolta Sensing Americas - compact / USB - image - 4
Add to favorites
Compare this product


Characteristics

Type
digital
Configuration
compact
Options and accessories
USB

Description

The CS-160 is a lightweight, compact and battery powered luminance and tristimulus colorimeter for the measurement of a wide range of luminance conditions and non-contact measurement of color. The CS-160 luminance and color meter allows luminance and chromaticity to be measured remotely with an acceptance angle of 1/3° for small light-emitting surfaces. It is the perfect marriage of efficiency and ergonomics with regards to spot measurements of color and luminance in a handheld portable instrument. The CS-160 provides an increased measurement range and a sensor that more closely matches the CIE 1931 color-matching functions. To provide the most accurate measurement of luminance and color, the relative spectral response of the measuring instrument should perfectly match the CIE color matching functions. Alongside improved usability, the CS-160 features an improved correlation to the color matching functions which yield more accurate results that closely correlate with visual evaluation and a greatly improved measurement range up to 9,999,000 cd/m2. Features • Eligible ISO 17025 Certification • 1/3° measurement angle • Luminance measurement range of 0.1 to 9,999,000 cd/m2 • Portable, lightweight, compact and battery powered(2xAA) • SLR (Single Lens Reflex), precise targeting; shows exact area to measure • Converts the color of the indicated area to numerical values • Quick measurements of the viewed object color without the influence of outside areas • Easy-to-read backlit display for viewing in dark areas • Includes Utility Software allows the instrument to be controlled from the PC via USB 2.0 • Various optional accessories such as illuminance adapter and close up lenses

VIDEO
