OCXO oscillator O-40-ULPN-100M
electronicultra-low-noisemedical

OCXO oscillator
OCXO oscillator
Add to favorites
Compare this product


Characteristics

Type
OCXO
Technology
electronic
Electrical characteristics
ultra-low-noise
Domain
telecommunication, measurement, medical
Frequency

100 MHz

Description

O-40-ULPN-100M is a high performance ‘Oven Controlled Crystal Oscillator’ (OCXO) offering exceptional Ultra Low Phase Noise (ULPN), and tight frequency stability. The part comes in a robust but still small hermetically sealed metal can package what makes it also suitable for humid environmental conditions. Features -135 dBc / Hz @ 100 Hz -185 dBc / Hz Noise Floor Low G Sensitivity ≤ 1 ppb / g Frequency stability up to ± 50 ppb Output signal: True Sinewave Electrical frequency tuning input Small hermetically sealed metal can package (25 x 25 mm) Supply voltage +5.0 V Operating temperature range up to – 40 to + 85 ºC Applications Instrument Reference Microwave Communication Systems Clock Reference for Microwave Signal Sources Radar Systems Medical Industry (e.g. Magnetic Resonance Tomograph)
