Alloy 32750 is a super duplex stainless steel supplied in the hot worked and solution annealed condition. As a super duplex stainless steel, it combines the desirable aspects of both austenitic and ferritic grades. The higher chromium, molybdenum and nitrogen contents result in a Pitting Resistance Equivalent number (PREN) of >40, providing pitting and crevice corrosion resistance superior to austenitic and duplex stainless steels in almost all corrosive media, and a Critical Pitting Temperature exceeding 50°C.
Supplied in the annealed condition it achieves yield strengths of 80ksi (550Mpa), greater than most austenitic and duplex stainless steel grades. It cannot be hardened by heat treatment but can be strengthened by cold working. It also exhibits a low coefficient of thermal expansion and higher heat conductivity than austenitic steels and is suitable for working temperatures up to 300°C. Alloy 32750 is listed in NACE MR 0175 for sour service and having gained ASME Approval for Pressure Vessel applications it can be used in a wide variety of applications.
Specifications
1.4410
X2CrNiMoN 25-7-4
Z3CND25.07Az
ASTM A240 F53
UNS32750 (Super Duplex 32750)
CE3MN (Cast grade)
25Cr
Key Features:
Pitting Resistance Equivalent number (PREN) of >40
Critical Pitting Temperature exceeding 50°C
High strength compared to austenitic and 22%Cr duplex stainless steels
Excellent ductility and impact strength at both ambient and sub-zero temperatures
High resistance to abrasion, erosion and cavitation erosion
Listed in NACE MR 0175 for sour service
ASME Approval for Pressure Vessel application
