Differential pressure gauge B32.ST

analogstainless steelBourdon tube

Best for measuring pressure of corrosive fluids (liquids & gas) in industrial processes. Application Oil and Gas Petrochemical Industry Electrical Equipment Mechanical Processing Food and Beverage Biopharmaceutical Industry Features Direct and Easy-to-Read Corrosion-Resistant Higher Protection Rating (IP44) Versatile in Different Environments Technical Specs Standards: - - - - EN837-1, GB/T1226 Certification: - - - - CPA (China), CRN (Canada) Pressure Limits: - Steady State: - - - - 3/4 x Full Scale Range Fluctuating: - - - - 2/3 x Full Scale Range Short Time: - - - - Full Scale Range Overpressure: - - ≤10MPa: - - - - 125% x Full Scale Range ＞10MPa，≤60MPa: - - 115% x Full Scale Range Temperature Effect: When the ambient temperature deviates from 20℃, the reading can deviated to a maximum of ±0.04% / 10K (degrees in Celsius/Kelvin). Wetted Material: - - - 304 / 316L Stainless Steel Pressure Element: - - - 316L Stainless Steel, C-type or Helical-type. Case Material: - - - - Stainless Steel Movement: - - - - Stainless Steel Dial: - - - - - - Aluminum. - - - - - - Black Text on White Background. Dual Scale Option. Pointer: - - - - - Aluminum. Black Window: - - - - - Glass, Safety Glass, Organic Glass Process Connection: - - Back, Bottom Filling Liquids: - - - - No Fill, Glycerin, Silicone, Others
