FEATURES
BUCKET CAPACITY
1 yard
PERFORMANCE
Capacity: up to 1,100 metric tons / hour
Throwing distance: up to 23 m (75 ft.)
DIMENSIONS
Length from the hitch plate: 1.96 m (77 in.)
Width overall: 2.26 - 2.51 m (89 - 99 in.)
Height overall: 1.93 - 3.15 m (76 - 124 in.)
Working height: 1.02 - 1.17 m (40 - 46 in.)
Weight: 1,750 kg (3,850 lbs.)
ENGINE
Power: 100 kW (134 HP)
Cummins F3.8 Turbo diesel
IMPELLER
5 blades - easy to replace
CONVEYOR
711 mm (28 in.) serrated ribbons
LOADING CHUTE
Hydraulic control
Throwing distance: 0.9 - 2.3 m (3 - 75 ft.)
OPTIONS
Female quick attach system
Conveyor-protecting side plates
Remote engine oil filter
Quick reset protection system (Flip Flange)
Hydraulic tilting chute
Chute extension of 0.6 - 1.2 m (24 - 48 in.)
DEL working lights on bucket and loading chute
Hydraulic lateral steering vanes
Battery charger
Battery heater
Chromium carbide drum
Chromium carbide chute
Trumpet horn
Full skid width
Carbide scraper blade
Wireless controls
