FEATURES
BUCKET CAPACITY:
2.5 yards
PERFORMANCE
Capacity: up to 2,750 metric tons / hour
Throwing distance: up to 46 m (150 ft.)
DIMENSIONS
Length from hitch plate: 2.083 m (82 in.)
Overall width: 2.8 to 2.9 m (110-114 in.)
Overall height: 3.53 to 3.99 m (139-157 in.)
Working height: 1.4 m (55 in.)
Weight: 4,490 kg (9,900 lbs.)
ENGINE
Power: 231kW (310 HP)
Cummins QSB6.7 Tier 4F
IMPELLER
5 blades - easy to replace
Heavy-duty impeller arms
Steel impeller casing - highly resistant to abrasion
Hydraulic impeller casing rotation
CONVEYOR
2 augers: 508 mm (20 in.) (serrated)
Icebreaker teeth
LOADING CHUTE
Hydraulically controlled
Horizontal rotation angle: 300º
Throwing distance: 1.2 to 15 m (4-50 ft.)
Telescopic section of 472 mm (18 in.) (optional)
OPTIONS
Female quick coupler
Hydraulic steering vanes
Impeller casting: 150° adjustable cast angle: from 30° left to horizontal (flat) to 0° right
Chromium carbide impeller casing
Chromium carbide chute
Tungsten carbide blade
Hydraulic tilt chute
Residential-type muffler
Heavy-duty rubber blade
Replaceable icebreaker teeth for conveyor
Work light on bucket and loading chute
Battery charger and/or battery heater
Telescopic chute: 472 mm (18 in.)
Trumpet horn
Wireless remote control
