CO2 laser marking and engraving machine Fantom F30

compact

The Fantom F30 is completely sealed, requires no gas connections and produces a beam that processes material at an average power of 30W. This is due to the combination of a low M2 (<1.3) high quality laser beam that allows smaller focus spot sizes and unique fast-rising square wave pulsing characteristics. F30 CO2 lasers can be pulsed at repetition rates up to 25 kHz. This unit offers 30W of power and output wavelengths of 10.6 microns. It provides the greatest flexibility to both end-users - Easily re-configured for direct installation into a production line; can connect to an external control device - Designed for maintenance-free Direct Part Marking [DPM] applications - I/O extension board (optically isolated 7 input and 5 output ports) - Built to operate under high shock, vibration, and dust conditions - Compact and lightweight laser head with easy alignment - F-Theta lens objectives with 150 mm or 300mm focal lengths - FiberScan C3™ software package - F30 system is air-cooled - Mounting hardware and cables - 3 meters of optical CO2 cable - Stand alone operation - “Plug and Play” system
